Cardstock is the material most cut files are made for, and it is also where most people meet their first bad cut: torn corners, shapes that will not release, or a design that is cut through in places and still attached in others.
Nearly all of it comes down to four things. Paper weight, blade, mat, and blade age. Settings come last, not first.
Match the setting to the weight, not the brand
Cardstock is sold by weight, and the weight is what your machine cares about.
| Weight | Feel | Design Space setting | Mat |
|---|---|---|---|
| 65 lb | Standard scrapbook cardstock | Cardstock (for intricate cuts) | LightGrip or StandardGrip |
| 80 lb | Heavier, holds a fold well | Medium Cardstock 80 lb | StandardGrip |
| 100 lb+ | Stiff, card-making weight | Heavy Cardstock 100 lb | StandardGrip |
| Glitter or foil | Coated, abrasive | Glitter Cardstock | StandardGrip |
If you do not know the weight, start one step lighter than you think and use the test cut. Cutting too light leaves the shape attached, which you can fix with another pass. Cutting too heavy chews the mat and the blade, which you cannot.
Blade
The fine-point blade handles everything above. It is the right default and the only blade most cardstock projects need.
The deep-point blade is for thicker material like chipboard and heavy poster board, and it is the wrong tool for ordinary cardstock: the steeper angle tears fine detail rather than slicing it.
Blade age matters more than any setting. A blade that has cut a few hundred sheets drags instead of cutting, and drag is what tears small connectors. If a design that used to cut cleanly has started failing, change the blade before you change anything else.
Mat
Use a StandardGrip mat for most cardstock. LightGrip works for 65 lb and is gentler on the paper when you unload it.
A mat that has lost its tack is a common hidden cause of bad cuts. If the sheet lifts even slightly during the cut, the blade pushes the paper instead of cutting it, and the result looks exactly like a pressure problem. Press the sheet down firmly with a brayer or your hand across the whole surface, not just the corners.
When the cut does not go all the way through
Work through these in order, because the list is roughly ordered by how often each is the culprit.
- Change the blade. Most common cause by a distance.
- Check the mat. If the paper lifted, nothing else matters. Re-stick or replace it.
- Clean the blade housing. A scrap of paper caught in the housing stops the blade spinning freely to follow curves.
- Use the correct material setting, and if you are between weights, choose the heavier one.
- Add a second pass. Set the cut to repeat rather than cranking pressure to maximum. Two moderate passes give a cleaner edge than one aggressive one.
- Only then increase pressure, and only one step at a time.
Intricate designs
Detailed cut files, mandalas and layered pieces especially, are where cardstock cutting gets demanding, because the design is mostly narrow connectors holding fragile shapes together.
Three things help. Cut them larger than feels necessary, since detail that fails at three inches often cuts perfectly at five. Use the Cardstock (for intricate cuts) setting, which is tuned for exactly this. And weed slowly from the center outward, lifting the waste away from the design rather than pulling the design off the mat.
To unload, turn the mat over and peel the mat away from the paper rather than lifting the paper off the mat. That single habit prevents most curling and tearing.
Frequently asked questions
What Cricut setting should I use for cardstock? Match the setting to the paper weight: Cardstock for 65 lb, Medium Cardstock for 80 lb, Heavy Cardstock for 100 lb and above. If you are unsure of the weight, start lighter and use a test cut, since a cut that is too light can be repeated and one that is too heavy damages the mat and blade.
Why is my Cricut not cutting all the way through cardstock? In order of likelihood: a worn blade, a mat that has lost its tack so the paper lifts mid-cut, debris in the blade housing, or the wrong material setting. Change the blade first, because it is the cause far more often than pressure is.
Which blade do I need for cardstock? The fine-point blade. The deep-point blade is for chipboard and heavy board, and its steeper angle tears fine detail in ordinary cardstock rather than cutting it cleanly.
Should I add more pressure or use two passes? Two passes. Repeating a moderate cut gives a cleaner edge and is kinder to the blade and mat than a single maximum-pressure pass, which tends to tear paper fibres and score the mat.
Why do intricate designs tear when I weed them? Narrow connectors are the weak point, and a dull blade drags across them instead of slicing. Cut the design larger, use the intricate cuts setting, use a fresh blade, and weed from the center outward so you pull waste away from the design rather than lifting the design itself.
How do I stop cardstock curling when I take it off the mat? Turn the mat upside down and peel the mat away from the paper, letting the mat bend rather than the sheet. Lifting the paper off a flat mat is what puts the curl in.
